LGK-120/200/300/400HD Inverter Air Plasma Cutting Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | GENWELD |
| Model Number: | LGK-120HD/LGK-200HD/LGK-300HD/LGK-400HD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 |
|---|---|
| Packaging Details: | 675×320×605/863×385×800/985×445×910/1015×445×910 |
| Delivery Time: | 5*8 days |
| Payment Terms: | T/T |
|
Detail Information |
Product Description
Main Features
With plasma torch consumables life monitoring function
With gas pressure and coolant liquid flow displaying, detecting,
warning and controlling function
The gas pre-flow, post-flow and current up-slope time can be set
separately
■ With automatic protection ofover-heating and lackvoltage
Error code displaying function
■ Intelligentfan is used to reduce the dust
■ LGK-120HD withconstantpilotarc strike function, which is suitable
for grid plate cutting
Product Application
Suit manual and automated cut for carbon steel,
alloy steel and nonferrous steel
Main Technical Parameters
| Item | Unit | Model | |||
| LGK-120HD | LGK-200HD | LGK-300HD | LGK-400HD | ||
| Input Power | V/Hz | 3～380±15%50/60 | |||
| Rated Input Capacity | KVA | 21.2 | 46.5 | 70.4 | 92.3 |
| Rated Input Current | A | 32.5 | 70.9 | 100 | 142 |
| Rated Output Current | A | 120 | 200 | 300 | 400 |
| Rated Output Voltage | V | 128 | 160 | 200 | 200 |
| Rated Open Circuit Voltage |
V | 308 | 360 | 370 | 370 |
| Rated Duty Cycle | 一 | 100%(40℃) | |||
| Efficiency | 一 | 92% | 93% | ||
| Power Factor | 0.78 | 0.92 | |||
| Output Current Adjust Range |
A | 30~120 | 40~200 | 60~300 | 60~400 |
| Arc Voltage Output Ratio | 一 | 1:1/1:20/1:50/1:100(Default 1:1) | |||
| Quality Cut Thickness (Carbon Steel) |
mm | 20(500mm/min) | 32(500mm/min) | 40(500mm/min) | 48(420mm/min) |
| Severance Cut Thickness (Carbon Steel) |
mm | 25(280mm/min) | 45(250mm/min) | 50(270mm/min) | 60(250mm/min) |
| Handheld Severance Cut Thickness (Carbon Steel) |
mm | 45 | 65 | 80 | 90 |
| Plasma Gas | Compressed Air | ||||
| Air Pressure | MPa | 0.5~0.8 | |||
| Coolant Working Flow | L/min | ≥2.7 | |||
| Power Source Cooling Mode |
Air Cooling | ||||
| Torch Cooling Mode | Air Cooling | Air Cooling /Water Cooling | |||
| Arc Strike Mode | Non-Contact | ||||
| Insulation Grade | 一 | F | |||
| Ingress Protection | IP21S | ||||
| Dimension (L×W×H) | mm | 675×320×605 | 863×385×800 | 985×445×910 | 1015×445×910 |
| Net Weight | Kg | 46 | 86 | 129 | 148 |
